What types of ore grinding machines are there?

Guilin Hongcheng, a well-known Ore grinding machine manufacturer, produces various ore mills with various finenesses. There are traditional Raymond mills (80~325 mesh ore powder), upgraded version of  Raymond mill called pendulum mills(80~600 mesh), ultrafine ring roller mills (80~1250 mesh), vertical mills and superfine vertical mills. The powder fineness ranges largely from 80 to 2500 mesh. The operation of the mill equipment is stable, environmentally friendly and energy-saving.

The selection of the ore mill depends on the fineness and capacity of the ore powder. A Raymond mill is usually chosen for producing about 20 tons the ore powder of a single machine with a fineness of 80-325 mesh. An energy-saving and high-producing vertical mill can be selected for an output of a single machine of more than 40 tons ore powder with a fineness of more than 325 mesh. And the ultra-fine vertical mill can be chosen for a  600-mesh ore powder of about 25 tons of a single machine. Definitely, it is also necessary to choose the model according to your investment needs. There are small, medium and large models of mills, which can be selected according to the financial situation.

The price of the mill depends on the types and the configured production line components. Guilin Hongcheng can customize the whole process for you with rich experience, providing a strong guarantee for your start-up and profit if you need EPC general contracting for the construction project of the ore pulverizer production line,

1. The use of ore powder

How much is a ton of ore powder? The price of non-metallic ore powder with different fineness is various. For the same ore, the finer the powder, the higher the price. Why should buy an ore mill production line to produce ore powder?

Ore powder can be used in daily necessities, building materials, ceramics, glass and refractory materials, chemical industry, agriculture, environmental protection, energy saving and other fields. Therefore, many powder factories purchase suitable ore mills for their needs to make ore powder and sell them.

2. Production process of ore mill: detailed explanation of process of producing ore powder

The first stage: The crushed large ore is transported to the raw material warehouse by a special vehicle, and then the material is sent to the jaw crusher by a forklift/person for crushing til it is smaller than the feed size of the mill

The second stage: the crushed ore is lifted to the storage hopper by the elevator, The material is discharged from the storage hopper and then fed to the main machine evenly by the feeder

The third stage: After grinding process, the qualified products are screened by the screening system and enter the collector through the pipeline. After collection, they are discharged through the discharge valve and become finished products, While the unqualified products fall into the main machine for re-grinding

The fourth stage: the airflow after the purification of the finished product flows into the blower through the residual air pipe above the dust collector. The air path is circular. Except for the positive pressure from the blower to the grinding chamber, the airflow in the other pipelines flows under negative pressure. The indoor sanitation is in good condition

3. Types of ore grinding machine

80~325 mesh ore mill:   Raymond mill and R series mill

(1)Traditional ore mill equipment: Raymond mill

     Raymond mill, also known as R series and pendulum mill, originated in the 1880s and was invented by the Raymond brothers. Raymond mill was introduced into China in the 1950s, and Guangxi of Guilin Province is one of the earliest production bases of pendulum mill in China. After more than 100 years of practice and continuous innovation and enhancement, the R-type Raymond mill (pendulum mill) has been improved in its structure. Guilin Hongcheng, as the research, development and manufacturing enterprise of Guilin Raymond Mill, has adopted advanced new technology for upgradation. The technical indicators of Hongcheng Raymond Mill have been greatly promoted, becoming the wind vane of domestic Raymond Mill technology innovation. There are several types of grinding rollers including: 2R, 3R, 4R, 5R, 6R.

Raymond mill R-type mill equipment parameters details are as follows:

[Model]: 2R2713, 3R3220, 4R3216, 4R3218, 4R3220, 5R4119,

5R4121, 5R4123, 6R5125

[Number of grinding rollers]: 2-6

[Diameter of grinding ring]: 780~1720(mm)

[Feeding size]: ≤25(mm)

[Particle size of finished product]: 0.18-0.038(mm)

[Capacity]: 0.3-20(t/h)

[Overall power]: 46~314(kw/h)

HC Series Pendulum Grinding Mill

(2)Upgraded mill: pendulum mill

HC Pendulum Mill, an upgraded version of Raymond Mill, is a large-scale grinding machine formed through innovation. This series of equipment is a truly high-efficiency, energy-saving and environmentally friendly large-scale mill developed by Guilin Hongcheng by referring to advanced German technology and adopting a number of patented technologies. The capacity reaches 90 tons per hour, meeting the national industrial policy and the ever-expanding demand for industrial scale production, making up for the blank of large-scale pendulum mills in China and expanding the application fields of pendulum mills. It greatly improves the user's equipment efficiency in terms of production capacity and unit energy consumption, and its technical level is internationally leading. The successful development of HC large-scale pendulum mill can replace almost all types of mills, especially suitable for large-scale powder processing in industries such as power plant desulfurization and manganese mining.

Modesl of the upgraded ore mill equipment-HC vertical pendulum mill are as follows

Upgraded version of ore mill equipment: HC Pendulum Grinding Mill

(Model): HC1000, HC1300, HCH1395, HCH2395, etc.

(Number of grinding rollers): 3-5

(Diameter of grinding ring): 1000-1700mm

(Feeding size): ≤25-30mm

(Particle size of finished product): 0.022-0.18mm

(Production capacity): 0.7-22t/h

(Processing materials): This product is suitable for grinding limestone, ore, activated carbon, ore, graphite, clay, kaolin, diabase, coal gangue, wollastonite, lime, zircon sand, bentonite, manganese ore and other materials.

(Advantages): This mill has very small vibration, low noise, stable mechanical operation, reliable performance, high output, low power consumption cost, high dust collection efficiency, and simple and convenient maintenance, becoming the equipment for large-scale powder processing.

    HCH Ultrafine Ring Roller Mill

(3) Ultrafine powder ore mill equipment: Ultrafine Ring Roller Mill

HCH ultra-fine ring roller mill is a new type of ultra-fine grinding mill equipment developed by Guilin Hongcheng with many years of production and research experience. It has comprehensive mechanical crushing properties such as rolling, grinding and impact, widely used for ultra-fine grinding mill of various non-metallic minerals such as ore, ore, calcium carbonate, ore, potassium feldspar, bentonite, kaolin, graphite, carbon etc. with Mohs hardness below 7 and humidity within 6%. It is a truly efficient and energy-saving ultra-fine crushing equipment, especially suitable for deep processing of non-metallic minerals.

The grinding mill has small floor area, strong integrity, wide use, simple operation, convenient maintenance, stable performance and high cost performance. It is an efficiency and energy-saving high fine powder processing equipment. The feeding size is ≤10mm, the finished product fineness is 0.04-0.005mm, and the capacity is 0.7-22t/h.

Parameters of ultrafine powder ore mill equipment - HCH ultrafine ring roller mill are as follows:

HCH Ultrafine Ring Roller Mil

〖Model〗: HCH780, HCH980, HC1300, HC1500, HC1700T, HC1700, etc.

〖Material size for grinding〗: ≤10mm

〖Overall power〗: 144-680KW

〖Overall weight〗: 17.5-70KW

〖Production capacity〗: 1-22t/h

〖Particle size of finished product〗: 0.04-0.005mm

〖Grinding field〗: For various non-metallic mineral materials with Mohs hardness below 7 and humidity within 6%, this mill is widely used in the grinding and processing of ore, ore, calcium carbonate, ore, potassium feldspar, bentonite, kaolin, graphite, carbon and other materials and fields such as electric power, metallurgy, cement, chemical industry, non-metallic ore milling, food, and medicine.

〖Performance characteristics〗: It has comprehensive mechanical crushing performances such as rolling, grinding, impacting, etc., focusing on the field of non-metallic ore deep processing, with small footprint, strong complete set, wide application, simple operation, convenient maintenance, stable performance, high efficiency and energy saving. HCH1395 and HCH2395 ultra-fine ring roller mills are new ultra-fine ring roller mills with large scale, energy saving and consumption reduction in China.

HLM Series Vertical Grinding Mill

(4) The rookie of mill equipment with high efficiency, energy saving and environmental protection: HLM Vertical Grinding Mill

HLM series vertical grinding mill is an advanced energy-saving mill equipment integrating drying, grinding, grading and conveying, developed by Guilin Hongcheng through learning and introducing foreign advanced technology and after more than 20 years of painstaking research and development.

Guilin Hongcheng’s HLM vertical roller mill has the advantages of high grinding efficiency, low power consumption, large feeding particle size, easy adjustment of product fineness, simple equipment process, small footprint, low noise, small dust, easy use and maintenance. It also has the advantages of low operating cost and low consumption of wear-resistant materials. It can be widely used in electric power, metallurgy, solid waste treatment, cement, chemical industry, non-metallic minerals and other industries, mainly used for grinding cement raw meal, clinker, power plant desulfurized limestone powder, slag powder, manganese ore, gypsum, coal, barite, ore, bauxite and other materials.

Parameters of vertical grinding mill are as follows:

*Middle diameter of grinding ring*: 800-5600mm

*Feeding particle size*: 50mm

*Production capacity*: 5-700t/h

*Particle size of finished product*: 22-180μm

*Motor power*: 450-6700kw

*Application field*: It is widely used in production and living fields such as electric power, metallurgy, cement, chemical industry, building materials, paint, paper making, rubber, medicine, food, etc.

*Practical materials*: It has high-yield and high-efficiency grinding capacity for various non-metallic mineral materials with Mohs hardness below 7 and humidity within 6%, such as cement raw meal, clinker, power plant desulfurized limestone powder, slag powder, manganese ore, gypsum, coal, barite, ore, bauxite, etc. The grinding effect is good.

HLMX Superfine Vertical Mill

(5) Ultrafine powder multi-head mill: HLMX Superfine Vertical Mil

 The ultra-fine vertical mill of HLMX series mill is a large-scale high-fine vertical mill developed by Guilin Hongcheng on the basis of  the advanced technology at home and abroad and the HLM vertical mill, which is suitable for the large-scale production of ultra-fine processing of non-metallic minerals.

Hongcheng HLMX vertical mill adopts ultra-fine powder multi-head classifier system, the product fineness can be adjusted between 325 mesh-2500 mesh (5μm-45μm), and the high output can reach 40t/h. It can be widely used in ultra-fine grinding processing of non-metallic mineral products such as limestone, ore, marble, heavy calcium, kaolin, barite, bentonite, ore, etc. It is an ultra-fine powder processing equipment with high efficiency, high output, environmental protection and energy saving.

Parameters of Ultrafine powder multi-head mill- HLMX Superfine Vertical Mill are as follows:

【Diameter of grinding ring】: 1000-2400mm

【Moisture of raw material】: ≤5%

【Production capacity】: 3-40t/h

【Product fineness】: 0-45μm with secondary classification can reach 5μm

【Product characteristics】: It integrates crushing, drying, grinding and conveying, breaks through the bottleneck of ultrafine powder processing capacity, can replace imported equipment, has scientific and reasonable design, unique and innovative structure, and is the first equipment for large-scale production of ultrafine powder.

【Fields】: Focus on the large-scale grinding and processing of coal mines, cement, slag, gypsum, ore, barite, fluorite, marble and other non-metallic minerals with Mohs hardness below 7 and humidity within 6%. The products have a number of national patented technologies, and their performance has reached the national leading level.

Guilin Hongcheng, a grinding machine manufacturer,  provides many types of ore grinding equipment, which can produce 80~2500 mesh ore powder. The types of grinding machine that the ore powder manufacturer purchases in large quantities include Raymond mill, ultra-fine ring roller mill, vertical mill, ultrafine vertical mill and other mill equipment, which are generally welcomed by the market. Hongcheng's customer experience is very good. It has a professional trial grinding center where the materials are tested and processed with incoming materials, and we will wholeheartedly provide customers with high-quality services.
